Jaw crusher
PE-750x1060
750 x 1060
mm, feed opening size
630
mm, max feed size
110-320
t/h, capacity
110
kW, motor power
29
t, weight
Capacity 110-320 t/h for medium quarries.
Availability
Made to order
Lead timeMade to order, 45 days from prepayment
What it is for
Quarries and cement plants planned from 110 t/h: granite, dolomite and limestone in lumps up to 630 mm. The first stage of a line up to 320 t/h, followed by a cone crusher and a three-deck screen.
When this model does not fit
Oversized below 80 t/h: 29 tonnes of machine, a dedicated foundation and 110 kW of connected power only pay off under a steady load. For a seasonal quarry or a mobile plant take the PE-600x900. It is not rated for lumps over 630 mm - oversize has to be broken with a hydraulic hammer on the receiving pad, which is another machine and another person per shift.
Technical specifications 5
| Feed opening size | 750 x 1060 mm |
|---|---|
| Max feed size | 630 mm |
| Capacity | 110-320 t/h |
| Motor power | 110 kW |
| Weight | 29 t |
Spare parts for this model 2
Similar models 2
400 x 600
Feed opening size, mm
340
Max feed size, mm
600 x 900
Feed opening size, mm
500
Max feed size, mm
Questions and answers 6
What is the lead time for equipment?
Machines held in our Oskemen warehouse ship within a week. Items made to order leave the factory in 8 to 12 weeks, plus transport to your site. We give an exact date once the specification is agreed: before that, any figure is a guess.
What happens if the delivery date is missed?
We report a delay on the day it becomes known, not on the shipping date, and send a new date with the reason. If the delay is our fault, the contract provides a penalty and we pay it. If the factory or customs moved the date, we show the documents instead of silently passing the wait on to you.
What information do you need to select a crusher?
The material and its strength, the feed size, the required product fraction, the capacity in tonnes per hour and the operating schedule. These five points are enough to offer two or three options. Without them, selection turns into selling whatever is in stock.
What does the warranty cover and what does it not?
The 12 month warranty covers manufacturing and assembly defects: frame cracks, bearing assemblies, drives, electrics. It does not cover wear parts such as plates, liners and blow bars, nor damage from running outside the rated duty: overload, uncalibrated feed, tramp metal. We explain that line before signing, not after a breakdown.
What counts as a defect and what as normal wear?
A defect is a fault of material or manufacture: a cavity in the casting, an unfused weld, hardness below the declared steel grade. Wear is even consumption of the working surface over service hours. A dispute is settled by measurement and dated photographs, and by a sample analysis if needed. Until the cause is established we neither refuse nor agree in advance.
How fast does a spare part arrive?
Wear parts for the common models are in stock and ship the same day. Items made to order take 3 to 6 weeks from the factory. We quote availability from the actual stock balance, not from a catalogue: if a part is not there we say so at once and offer an equivalent or a date.
